„Magnetom Vida“
Complete cover solution of an MRI scanner
Siemens Healthcare GmbH
„ARTIS Pheno“
Complete cover of a robot
Siemens Healthcare GmbH
„Crane cover“
Outer covers for mobile cranes
Manitowoc
„S4 T-Star“
Complete housing of an analysis device
Bruker Nano
„Toll Collect“
Covers of Toll Collect terminals
krauth technology GmbH
„Foam air ducts“
Twin-Sheet foam air ducts for commercial vehicles and automotive
for various customers
„Somatom Force“
Cover of a computer tomograph unit with lighting elements
Siemens Healthcare GmbH
Hier ist alternativer Text
„Easy.Gate“
Aerial and signal housing for Easy.Gate
Skidata
„Helmo VUE“
Cover of an industrial robot
Stäubli
„FE35, FE55 und FE75“
High-end machine covers
Fette Compacting GmbH
„Xcite“
Machine covers of a press brake
Bystronic Maschinenbau GmbH
„Sagi Nova“
Cover of a therapy device
Fette FE Terminal
„Fette User Interface“
Terminal
Fette
„RW10“
Cover of a gypsy winch
Bagela
„Twin-Sheet pipe distributor“
Pipe distributor for wastewater­treatment­plants
Koch Membrane Systems
„rapifleX MALDI / timsTOF fleX“
Twin-Sheet screen with lighting
Bruker Daltonik
„Laser Autonom“
Cover of a laser cutting machine
Bystronic Laser AG
„Ecodry Plus“
Housing of a vacuum pump
Leybold
„Somatom Definition Flash“
Cover of a computer tomograph unit
Siemens Healthcare GmbH
en text
„Nano Temper TychoNT.6“
Complete housing for an analysis device
Nano Temper
„User-Interface Terminal“
Supporting structural component for the user interface terminal of corrugated paper plants
BHS Corrugated
„MAGNETOM Skyra FIT“
Complete cover of an MRI scanner
Siemens Healthcare GmbH
„OCE“
Covers of a digital printer
OCE
„Magnetom Verio 3T“
Complete cover solution of an MRI scanner
Siemens Healthcare GmbH
„Heat exchanger“
Heat exchanger
„Development Air/air-heat exchanger“
Development, prototyping as well as production setup of Twin-Sheet heat exchangers
„180l Bioreactor“
Algae cultivation reactor
Subitec

MAGNETOM Vida

Complete cover solution of an MRI scanner

Project scope

Development, construction, prototyping and series production of the entire cover assembly of the MAGNETOM Vida system incl. connection and simultaneous decoupling from the magnet.

Requirements

  • Chem. resistance against cleaning agents
  • Biocompatibility
  • Fire protection in accordance with UL 94 V-0
  • Design effect in the area of “coloured” cover options
  • Light but rigid components

Highlight of the project

Front and rear trim as highly rigid components, to which almost all other cover components are attached. This saves a complex and costly substructure.


Range of services

Development and construction of the complete cover assembly based on design data and the attachment points to the magnet below.

The development considered all qualitative, technical and economical requirements.

The assembly consists of more than 600 individual components and comprises a number of manufacturing technologies available on the market, such as:
Twin-Sheet, thermoforming, injection moulding, TSG, GFK, RTM, PUR, laser-edge flexible parts and extrusion.

Hombach created product-quality prototype parts and delivers the complete assembly in series “”just-in-time”, including all mechanical and electrical and electronic components, ready to the customer’s assembly line.

The components are structure- or high-gloss-painted.
Flexible structure-paint systems are in part applied to the flexible foam parts.




All products and parts in our showroom represent a small part of our implemented projects. We will be pleased to check your projects for feasibility and economic efficiency free of charge at any time, or we can provide you with recommendations for suitable technologies.

(c) PLEASE NOTE that all images shown here are subject to the copyright of Ernst Hombach GmbH & Co. KG, of our customers or commissioned photographer. Photos must only be used for other publications, marketing campaigns or similar with written approval.
